    MIL - STD WATER IP Test IEC ip3 ip6 Tait Standards IP Test Equipment

    Ask Lasest Price
    Brand Name : Haida
    Model Number : HD-E710
    Certification : CE,,ISO
    Price : Negotiation
    Payment Terms : L/C, T/T, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 300 Sets per Month
    Delivery Time : 20 days after order confirmed
    • Product Details
    • Company Profile

    MIL - STD WATER IP Test IEC ip3 ip6 Tait Standards IP Test Equipment

    MIL - STD WATER IP Test IEC ip3 ip6 Tait Standards IP Test Equipment​


    Water Spray Test Chamber.pdf


    Description:

    MIL - STD WATER IP Test IEC ip3 ip6 Tait Standards IP Test Equipment​ used to test anti-rain and waterproof performance for products, the products such as steam locomotive lamps, wiper performance, waterproof bands, motorcycle instruments, defense industry, navigation systems, missiles, radar cone top, aerospace industry,IEC IP code specifications that need an additional discussion.


    Features of
    MIL - STD WATER IP Test IEC ip3 ip6 Tait Standards IP Test Equipment​:

    MIL - STD WATER IP Test IEC ip3 ip6 Tait Standards IP Test Equipment​ can perform tests according to the following standards. However, standardised special options are sometimes necessary to fulfil these.

    • DIN EN 60 529-1:2000
    • DIN EN 60 034-5:2001
    • DIN 40 050-9:1993
    • DIN IEC 68, T2-18, method Rb 2.1
    • SAE Standard J575, 1993 (option)
    • JIS D 0203 – 1994, Tests R1/R2/S1/S2 (option)
    • MIL-STD-810F, Method 506.4 (option)

    With the Weiss standard Spray and Splash Water Test Systems tests according to IP X3 and IP X4 can be performed. Picture 1 shows a principle sketch of a test according to DIN EN 60 529.



    Parameters of
    MIL - STD WATER IP Test IEC ip3 ip6 Tait Standards IP Test Equipment​:

    Model

    HD-E710

    Studio size

    (D×W×H)80 ×130 ×100cm

    Swing pipe diameter

    0.4m, 0.6m, 0.8m, 1.0m (according to the size of the measured object to select the swing pipe size)

    Pendulum tube angle

    60 degrees ,vertical ± 90 and 180 degrees

    Orifice

    The removable design, pinhole 0.4mm, specially designed nozzle, spray rain rain water pressure 50-150kpa

    Testing temperature

    Room temperature

    Specimen rotative speed

    1-3r/min (Adjustable)

    Power

    1 phase, 220V, 5KW

    Weight

    approx.350kg


    Application

    • IP X1/X2 (drip device, Option)
    • IP X3/X4 (swivelling tube, Standard)
    • IP X3/X4 (spray head, Option)
    • IP X5/X6 (jet nozzle, Option)
    • IP X9K (high pressure jet nozzle, Option)



    Water Dripping Test (Meet IPX1 and IPX2 test)

    1. LCD touch screen controller with PLC control
    2. Drip box size: 1000x1000mm (or 500x500mm),or custom size as option
    3. Needle diameter: 0.4mm
    4. Distance between needle: 20mm
    5. Dropping rate: 1mm+0.5mm/min (IPX1),3mm+0.5mm/min (IPX2)
    6. Dropping height: 200mm (adjustable)
    7. With timer, flow display
    8. With rotating table, diameter 700mm, 1rpm,
    9. 15o tilt plate, height adjustable
    10. Meet IEC60529, IEC60598


    Water Pumping System (For IPX1,2, IPX3,4, IPX5,6)

    1. Water pump for large flow: 0-7m3/h
    2. Water pump for small flow: 0-3m3/h
    3. Water inlet
    4. With water filters
    5. Pressure display and water flow display
    6. Safety overload protection on pump and motor


    PLC Controller:

    1. PLC + touch screen interface
    2. test parameter setting and monitoring



    IPX Material Waterproof / Rain Spray / Water Mist Spray / Lamp Rain Test Chamber view:

    MIL - STD WATER IP Test IEC ip3 ip6 Tait Standards IP Test Equipment
    MIL - STD WATER IP Test IEC ip3 ip6 Tait Standards IP Test Equipment


    (Water Flow Meter)


    Our Services

    After-service

    If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by customer.


    Flow chartaFlow chartb


    FAQ

    Why choose us?

    1. Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.

    2.Excellent After sale Service:
    18 months warranty. Besides, we can help you to repair your problem controller freely, even it's not from our factory. What you need to do is to send us the controller.

    3.Commitment:
    We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.

    4.Good Packaging:

    Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
