    Custom Electronic Uniaxial Tension Material Tensile Tester Tension Testing Machine

    Ask Lasest Price
    Brand Name : Haida
    Model Number : HD-B611S
    Certification : CE,,ISO
    Price : Negotiation
    Payment Terms : L/C, T/T, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 100 Piece / Pieces Per Month
    Delivery Time : 15 Days After Order
    • Product Details
    • Company Profile

    Custom Electronic Uniaxial Tension Material Tensile Tester Tension Testing Machine

    Custom Electronic Uniaxial Tension Material Tensile Tester Tension Testing Machine

    HD-B611-S Universal Test Machine.pdf
    Product Description

    Tensile Testing Machine is widely used in wires & cables, hardware, metal, rubber, footwear, leather, apparel, fabric, tape paper products, pharmacy and so on, for tensile strength, tear resistance, peel strength, bend strength, shear force , ect with different fixtures according to national and international standards customer required.

    This Machine is a kind of electric tensile tester which uses the motor to drive ball screw to move fixture. Place the fixture with sample between the upper and lower fixture, use a given speed to pull sample upward by upper fixture. Load cell above upper fixture will sense tensile strength, and convert the strength into voltage sign and output to the display screen. And the strength value will be displayed automatically.

    Main Technical Parameters

    Items

    Specification

    Sensor

    Celtron load cell

    Capacity

    1000,2000,3000,5000kg,10000kg

    Unit Switchover

    G, KG, N, LB

    Display Device

    PC

    Resolution

    1/250,000

    Accuracy

    ±0.5%

    Max. Stroke

    1000mm (including fixture)

    Test Speed

    0.1-300mm/min (adjustable )

    Motor

    Panasonic Servo Motor

    Screw

    High Precise Ball Screw

    Elongation Accuracy

    0.001mm

    Power

    1 ø,AC 220V, 50HZ

    Weight

    Approx.250kg

    Accessories

    One set tensile clamp,one set Lenovo computer, one piece English software CD, one piece operation video CD, one piece English user manual


    Features of Tensile Testing Machine:

    1. Motor system: Panasonic servo motor +Servo driver +High precise ball screw (Taiwan).
    2. Displacement resolution: 0.001mm.
    3. User can set parameters of product material such as length, width, thickness, radius, area and so on.
    4. Control system: a, computer control with TM2101 software; b, Back to origin automatically after the test, c, store data automatically or by manual operation.
    5. Data transmission: RS232.
    6. It can save results automatically after test finished, and it is manual filing. It can display maximum force, yield strength, compressive strength, tensile strength, elongation, peel interval maximum, minimum and average, etc.
    7. Graph scale automatic optimization can make graph to display with best measurement and can implem- ent graphics dynamic switching in the test and has force-elongation, force- time, elongation -time, stress - strain.
    8. Many languages random switching: Simplified Chinese, Traditional Chinese, and English.

    Application of Industry:

    Custom Electronic Uniaxial Tension Material Tensile Tester Tension Testing Machine widely used measure quality; rubber and plastics; metallurgical steel; machinery manufacturing; electronic appliances; automobile production; textile and chemical fiber; wire and cable; packaging materials and food; instrumentation; medical equipment; civilian nuclear energy; civil aviation; universities; research laboratory; inspection arbitration, technical supervision departments; building ceramics; petrochemicals; other industries.

    Optional Note:

    How to buy
    Custom Electronic Uniaxial Tension Material Tensile Tester Tension Testing Machine

    First, the different materials testing machine needs:

    1. Metallic materials testing machine requirements
    2. Plastic material (polymer) of the test machine requires
    3. Plastic pipe requirements for testing machines
    4. Rubber material testing machine requirements
    5. Textile fiber materials required for the testing machine
    6. Required spring bearing on the testing machine
    7. Film, foil material testing machine of claim
    8. Products (or product) of the test machine requires
    Second, there are different needs in different sectors of the test machine.

    Circuit Board

    Packaging & Shipping

    Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
