Microcomputer Control Electronic Tensile Tester Rubber Testing Equipment

    Buy cheap Microcomputer Control Electronic Tensile Tester Rubber Testing Equipment from wholesalers

    Buy cheap Microcomputer Control Electronic Tensile Tester Rubber Testing Equipment from wholesalers
    • Buy cheap Microcomputer Control Electronic Tensile Tester Rubber Testing Equipment from wholesalers
    • Buy cheap Microcomputer Control Electronic Tensile Tester Rubber Testing Equipment from wholesalers
    • Buy cheap Microcomputer Control Electronic Tensile Tester Rubber Testing Equipment from wholesalers
    • Buy cheap Microcomputer Control Electronic Tensile Tester Rubber Testing Equipment from wholesalers

    Microcomputer Control Electronic Tensile Tester Rubber Testing Equipment

    Ask Lasest Price
    Brand Name : Haida
    Model Number : HD-B609B-S
    Certification : CE,,ISO
    Price : Negotiation
    Payment Terms : L/C, T/T, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 100 Piece / Pieces Per Month
    Delivery Time : 15 Days After Order
    • Product Details
    • Company Profile

    Microcomputer Control Electronic Tensile Tester Rubber Testing Equipment


    Microcomputer Control Electronic Tensile Tester Rubber Testing Equipment

    Product Description

    Microcomputer Control Electronic Rubber Tensile Strength Testing Machine are suitable for tensile, compression and all other special load test for non metal material for example, plastic, rubber, thread, wood, alloy, PVC, electrical wire and cable, composite, profiled bar, waterproof roll, etc. Add relative optional accessories, it is easy to achieve the test of bending, shearing, peeling, friction, tearing, puncture and hardness test. They are essential testing instruments for quality testing section, university and college, research institution and industrial and mining enterprise.

    The machine is calibrated as ASTM E4, ISO 75001 international standard. By adding different grips it can do the test of ISO 527, ISO 8295, ISO 37, ISO 178, ISO 6892, ASTM D412, ASTM C1161, ASTM D882, ASTM D885ASTM D918, ASTM D1876, ASTM D4632 and all the force and extension JIS, DIN, BSEN testing standards.



    Main Technical Parameters of Electronic Rubber Tensile Strength Testing Machine:

    Items

    Specification

    Sensor

    Celtron load cell

    Capacity

    5, 10, 20, 25, 50, 100, 200kg

    Unit Switchover

    G, KG, N, LB

    Display Device

    LCD or PC

    Resolution

    1/250,000

    Accuracy

    ±0.5%

    Max. Stroke

    1000mm (including fixture)

    Test Speed

    0.1-500mm/min (adjustable )

    Motor

    Panasonic Servo Motor

    Screw

    High Precise Ball Screw

    Elongation Accuracy

    0.001mm

    Power

    1ø,AC220V, 50HZ

    Weight

    Approx.75kg

    Accessories

    One set tensile clamp, one set Lenovo computer, one piece English software CD, one piece operation video CD, one piece English user manual



    Features of Microcomputer Electronic Rubber Tensile Strength Testing Machine:

    1, cleared automatically: Before the test, is automatically cleared
    2, the automatic transmission: test speed during the test according to the speed of advance run, optionally also change the speed as needed.
    3, showing the value check: The system can achieve accurate calibration force values.
    4, the display method: liquid crystal display, a force value data directly show elongation value is automatically displayed
    5, limit protection: with automatic limit protection.
    6, a machine: with different sensors, can achieve more than one machine.


    Optional Note:

    How to buy electronic universal testing machine:

    First, the different materials testing machine needs:

    1. Metallic materials testing machine requirements

    2. Plastic material (polymer) of the test machine requires

    3. Plastic pipe requirements for testing machines

    4. Rubber material testing machine requirements

    5. Textile fiber materials required for the testing machine

    6. Required spring bearing on the testing machine

    7. Film, foil material testing machine of claim

    8. Products (or product) of the test machine requires


    Second, there are different needs in different sectors of the test machine.



    Microcomputer Control Electronic Rubber Tensile Strength Testing Machine view:
