5062-HD Toilet Seat Impact Tester with LCD Screen

    Buy cheap 5062-HD Toilet Seat Impact Tester with LCD Screen from wholesalers

    Buy cheap 5062-HD Toilet Seat Impact Tester with LCD Screen from wholesalers
    • Buy cheap 5062-HD Toilet Seat Impact Tester with LCD Screen from wholesalers
    • Buy cheap 5062-HD Toilet Seat Impact Tester with LCD Screen from wholesalers

    5062-HD Toilet Seat Impact Tester with LCD Screen

    Ask Lasest Price
    Brand Name : Haida
    Model Number : 5062-HD
    Certification : ISO
    Price : Negotiable
    Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash,escrow
    Supply Ability : 30 Sets per Month
    Delivery Time : 20 days after order confirmed
    • Product Details
    • Company Profile

    5062-HD Toilet Seat Impact Tester with LCD Screen

    APPLICATIONS & TEST PURPOSE:

    This machine is designed for the measurement of electronics, electrical appliances, home appliances, plastics, communication and other finished products or components in the installation of the process of collision and design, so as to assess whether the product structure is bad or not enough test test, to a certain specified weight of the steel ball, in a certain height of the free fall, the impact of the test material, components, to observe the degree of damage to the product.

    Test Procedure:

    ØA steel ball with a diameter of 38 mm and a mass of 0.225 kg was dropped freely from a height of 455 mm to the center of the front of the center ring and the center of the middle of the ring. The impact positions are shown in Fig.

    STANDARD

    JC/T 764-2008 5.4.7

    STANDARD FAETURES:
    FeatureSpecification
    Impact height range0-1000mm (manually adjustable, steel ruler shows scale)
    Specimen sizeToilet seat size
    Drop height displayGraduated steel ruler indicates vertically
    Drop height accuracy1mm
    Drop bar shapeSquare rod
    Control and lifting methodCircuit-controlled electromagnet suction cup, manually lifting and lowering electromagnet fixing rod
    Alignment deviceInfrared positioning, convenient for customers' fixed-point testing
    Impact ball specification225g (φ38mm)
    Control boxProtective mesh box around the bottom
    VolumeApprox. 1000*1000*1050mm
    Power SupplyAC220V 50Hz
